What can AQUATHERM RED do?
aquatherm red is the first plastic sprinkler pipework system to be certified by VDS Schadenverhütung GmbH, Europe’s largest institute for corporate security. The material used, fusiolen PP-R FS, was developed to meet the specific requirements of sprinkler systems. Thanks to its flame-retardant properties and corrosion resistance, aquatherm red offers a high level of safety and durability. Furthermore, the welding of pipes and fittings ensures a leak-proof connection.
What should you know about AQUATHERM RED?
The entire pipework system using aquatherm red pipes, from the main pipe to the sprinkler/wall hydrant, is covered by the available diameters: 25, 32, 40, 50, 63, 75, 90, 110 and 125 mm (DN15 – 90).
The SDR (Standard Dimension Ratio) is a parameter used to indicate pressure resistance. To ensure a certain level of pressure resistance, a specific maximum SDR value is required, depending on the type of material. The following applies: the greater the wall thickness, the lower the SDR value and the greater the pressure resistance of the plastic pipe. The unit indicates the ratio between the outer diameter and the wall thickness of a pipe.
aquatherm red is available in SDR size 7.4.
aquatherm red is made from fusiolen PP-R FS. Thanks to its flame-retardant properties and corrosion resistance, this plastic pipe offers a high level of safety. aquatherm red is suitable for direct installation in concrete. By way of comparison: when metal sprinkler systems are used, corrosion occurs as soon as the metal comes into contact with damp concrete. Corrosion can only be prevented with the aid of special protection, which makes the installation of metal pipework systems in concrete complex and expensive. The pipework system is suitable not only for wet sprinkler systems (in concrete or F30 ceiling areas), but also for low-pressure fine-spray technology.
Frequently asked questions from customers about AQUATHERM RED
You may only use aquatherm red in sprinkler systems. aquatherm red is not suitable or approved for use in drinking water systems.
The aquatherm PP-R FS sprinkler pipework system meets the requirements of building material class B 1 according to DIN 4102-1 and B-s1,d0 according to DIN EN 13501 (flame-retardant). Compared with natural materials such as wood, cork or wool, they do not exhibit increased fire gas toxicity. Consequently, no dioxin is produced during combustion.
Your aquatherm contact is happy to assist you with further information or specific project enquiries.
All fire protection systems that can provide evidence of the relevant approval are suitable for aquatherm red pipework.
The following companies offer suitable fire protection solutions:
Conlit 150 U fire protection pipe sleeve
:
DEUTSCHE ROCKWOOL
GmbH & Co. KG
Rockwool Straße 37–41
45966 Gladbeck
Tel: +49 2043 408 0
www.rockwool.de
AWM II fire protection collar
:
Flamro Brandschutz
Vertriebs GmbH
Am Sportplatz 2
56291 Leiningen
Tel. +49 6746 9410-0
Email: info@flamro.com
www.flamro.de
Hilti Deutschland AG
Hiltistrasse 2 · 86916 Kaufering
Tel: +49 800 888 · www.hilti.de
For exposed installations in accordance with LPCB guidelines, use only approved quick-response sprinklers.
- Plastic pipes and fittings are approved exclusively for the installation of wet systems.
- Particular care must be taken with the joining method; it is essential to follow the installation instructions, particularly with regard to the
required cooling-off period, before the system is pressurised with water. - Plastic pipes and fittings must not be used outdoors.
- Do not use as drinking water pipework.
VdS requirements/conditions:
- Suspended sprinkler systems only.
- To be installed only as main and distribution pipes.
- Installation between a concrete ceiling and a suspended ceiling (min. F30) up to DN50; no fire loads are permitted in the false ceiling.
- Piping cast into concrete up to DN90.
- Installation must be carried out only by trained and VdS-approved specialist personnel.
- Use only VdS-approved sprinkler heads.
- Use only VdS-approved pipe clamps/pipe loops.
- Design and installation in accordance with the VdS CEA 4001 guideline for sprinkler systems.
- For longer horizontal pipe runs, an expansion joint must be fitted every 40 metres.
- Approved for use as a wet system in false ceiling areas (min. F30) for pipe diameters from 25 mm to 75 mm (DN15–DN50). Permissible pressure 12.5
- Approved for use as a wet system in concrete for diameters from 25 mm to 125 mm (DN15–DN90). Permissible pressure: 18 bar. Operating parameters:
Max. operating temperature: 10–49°
Max. operating pressure: 12.5 bar
(18 bar for installation in concrete) - Calculated service life of the pipework components under these conditions: 100 years (in accordance with DIN 8077/78/DIN EN ISO 15874).
- Suitable for low-risk applications (LH, OH up to OH3 and OH4, restricted to exhibition halls, cinemas, theatres and concert halls).
aquatherm red pipes can be stored at any outside temperature. The storage area should generally be chosen so that the pipes are always supported along their entire length. The pipes must not be allowed to bend during storage or transport. At sub-zero temperatures, there is a risk that the pipes may be damaged by heavy impacts. The material must therefore be handled with care at low temperatures.
Despite their high durability, aquatherm pipes should always be handled with care. UV radiation can impair the properties of polypropylene and other high-polymer plastics. Therefore, unprotected, long-term outdoor storage of aquatherm pipework systems should be avoided. Outdoor storage is permitted only in the undamaged original packaging and for a maximum period of 6 months from the date of delivery.
